Coil Heater
EaseWise Coil Heaters provide uniform heating for injection molding, extrusion, hot runner systems, and other industrial applications. Available in stainless steel (304/316) and brass, these heaters can be customized by inner diameter, wattage, voltage, lead configuration, and dimensions. As a coil heater supplier, EaseWise supports OEM heating requirements worldwide.
Learn how a coil heater works, including its heating principle, construction, temperature control, and common industrial applications.
Wide Application
Injection Molding
Coil heaters are widely used on injection molding machine nozzles and barrels, providing uniform external heating for consistent melt temperature and shot-to-shot repeatability.
Hot Runner Systems
Precision heating for hot runner manifolds and nozzles, ensuring stable melt flow and minimizing cold slug formation in multi-cavity molds.
Extrusion
Applied on extruder barrels and die heads, coil heaters deliver even heat distribution for consistent material processing across thermoplastics and engineering resins.
Packaging & Sealing
Used in heat-sealing bars, shrink tunnels, and packaging machinery where compact, high-temperature heating elements are required.
Why Choose EaseWise Coil Heaters
- Dual Material Options — Stainless steel (304/316) for demanding environments, or brass for general-purpose heating.
- Custom Heating Design — Configurable inner diameter, heating width, wattage, lead wire length, and termination style.
- Reliable Quality — Resistance, insulation, and dimensional tolerances are checked before shipping.
- Flexible Lead Time — Standard sizes typically ship within 5–7 working days; custom orders typically require 10–15 working days.
- Competitive Pricing — Suitable for samples, OEM projects, and volume orders.
SS Coil Heater Range
Stainless Steel and Brass Coil Heater Options
EaseWise coil heaters are available in stainless steel and brass, with inner diameters from 20 mm to 200 mm+ and wattages up to 1000 W+. Key specifications include:
| Parameter | SS Coil Heater | Brass Coil Heater |
|---|---|---|
| Material | 304 / 316 Stainless Steel | High-Conductivity Brass |
| Inner Diameter | 20–200 mm+ | 20–200 mm+ |
| Width | 20–60 mm | 20–60 mm |
| Wattage | 100–1000 W+ | 100–800 W+ |
| Maximum Operating Temperature | 750°C (304) / 850°C (316) | 400°C |
| Lead Wire | Fiberglass / Silicone / PTFE | Fiberglass / Silicone |
| Termination | Flying Leads, Terminal Box, Ceramic Connector | Flying Leads, Terminal Box |
When selecting a coil heater, consider the material, watt density, inner diameter tolerance, and installation dimensions. These factors help ensure efficient heat transfer and stable heating performance. EaseWise can help specify the right configuration for your equipment and heating requirements.
- Coil Heater Applications — Heating solutions for injection molding, extrusion, hot runner systems, packaging, and industrial equipment.
- Micro & Mini Coil Heater — Compact heaters for limited installation space.
- Square Coil Heater — Custom heating elements for specialized configurations.
- Hot Runner Spring Coil Heater — Flexible heaters for hot runner and injection molding systems.
- Hot Runner Heater Applications — Heating solutions for hot runner systems and plastic processing equipment.
For a custom configuration, Request a Quote with your required diameter, width, wattage, voltage, material, and lead wire configuration.
Request a Quote
Ready to order or need a custom coil heater?
Explore our full Coil Heater product range →
Frequently Asked Questions
Stainless steel coil heaters excel in high-temperature environments (up to 850°C) and offer superior corrosion resistance, making them ideal for demanding industrial applications. Brass coil heaters provide significantly better thermal conductivity — meaning faster heat-up and more uniform heat transfer — and are well-suited for general-purpose injection molding below 400°C. The choice comes down to your operating temperature and environment rather than a simple cost comparison.
Yes. We customize inner diameter, width, wattage, lead wire length and type, and termination style. Send us your specifications for a quote.
Sample orders of 1-5 pieces are accepted. For production orders, MOQ typically starts at 10-50 pieces depending on the specification.
