One-Piece Mica Band Heater
The One-Piece Mica Band Heater is a closed-loop heating unit designed for small-diameter barrels and short heating zones in injection molding machines. Its integral structure has no side opening, providing close contact with the barrel surface for stable and efficient heat transfer.
Unlike split-type mica heaters, this one-piece design must be installed from the end of the barrel. It is especially suitable for applications where a compact heater with a close fit is required. Custom sizes, voltage, power, terminals, and optional insulation are available for different machine requirements.
For the complete range of mica heating solutions, visit our Mica Band Heater product page. For other industrial band heating solutions, explore our Band Heater Solutions.
Product Features
- One-piece integral closed-loop structure with no side opening
- Close fitting for efficient heat transfer to the barrel
- Designed for small-diameter barrels and short heating zones
- High-temperature mica insulation for stable operation
- Stainless steel 304 outer sheath for industrial durability
- Maximum working temperature up to 420–450°C
- Optional inner insulation layer for improved energy efficiency
- Custom sizes, voltage, power, and terminal configurations available
Technical Parameters
| Parameter | Specification |
|---|---|
| Structure | One-piece integral closed-loop, no side opening |
| Outer Sheath | Stainless Steel 304; brass sheath optional |
| Insulation Material | High-temperature mica sheet |
| Maximum Working Temperature | 420–450°C |
| Voltage Range | 110V–480V, customizable |
| Power Density | 1.5–2.2 W/cm², standard |
| Terminal Options | Screw terminal / Stainless steel braided lead / Terminal box |
| Installation | Slide over from barrel end and fix with clamp band |
| Optional Features | Inner insulation layer; thermocouple hole upon request |
| Application | Small-diameter barrel, short heating zone, injection machine barrel heating |
Stock Reference Sizes
Most one-piece mica band heaters are custom-made according to the barrel diameter and heating width. The following are limited stock reference sizes:
| Inside Diameter (ID) | Width | Common Stock Voltage |
|---|---|---|
| 40 mm | 40 mm | 220V |
| 50 mm | 40 mm | 220V |
| 60 mm | 50 mm | 220V |
| 65 mm | 50 mm | 220V |
| 70 mm | 50 mm | 220V |
| 75 mm | 60 mm | 220V |
Common stock voltage: 220V
Remarks:
- Stock items follow standard industry power settings.
- Sizes outside the stock list require OEM customization.
- Stock heaters do not include thermocouple holes. Thermocouple holes are available upon request.
Installation
The one-piece structure has no side opening, so the heater must be installed by sliding it over the barrel from the barrel end. After positioning the heater correctly, it is secured with a clamp band to maintain close contact with the heating surface.
Before installation, confirm that the heater inside diameter matches the barrel outside diameter. Correct fitting helps maintain efficient heat transfer and stable heating performance.
Applications
This one-piece mica heater is mainly used for:
- Small-diameter injection molding machine barrels
- Short heating zones
- Plastic processing equipment
- Compact cylindrical heating applications
- Injection machine barrel heating
Custom One-Piece Mica Band Heater
EaseWise supports OEM customization for different industrial heating requirements. We can manufacture one-piece heaters according to your barrel dimensions, electrical requirements, drawings, or samples.
- Custom inside diameter
- Custom heater width
- Custom voltage
- Custom power
- Custom power density
- Custom terminal configuration
- Optional inner insulation layer
- Thermocouple hole customization
- OEM production according to drawings or samples
Related Mica Band Heater Products
Compare this closed-loop design with other configurations in the EaseWise mica band heater range:
- Mica Band Heater – Complete range and selection overview
- Standard Split Mica Band Heater – Open-end design for easier installation and replacement
- Nozzle Mica Band Heater – Compact solution for injection machine nozzles
Related Mica Band Heater Information
Contact EaseWise
For pricing, stock availability, or a custom one-piece mica band heater, please provide the barrel outside diameter, heater width, voltage, power, quantity, and application.
Request a Quote for a One-Piece Mica Band Heater
Amy – Sales
Email: Amy-Easewise@tzheater.com
WhatsApp: +86 188 8318 8154
Hanna – Sales
Email: Hanna-Easewise@tzheater.com
WhatsApp: +86 173 5163 6811
One-piece mica band heaters are designed for small-diameter barrels and short heating zones. Custom sizes, voltage, power, and terminal configurations are supported.
