Medical Silicone Rubber Heater for Medical Equipment and Laboratory Applications

Medical Silicone Rubber Heater is a thin, flexible heating element for medical equipment, laboratory instruments, diagnostic devices and analytical systems that require controlled surface heating and temperature maintenance.

Technical Specifications

Parameter	Specification
Structure	Flexible silicone rubber with embedded nickel-chromium heating wire
Surface Material	High-temperature silicone rubber
Insulation Withstand Voltage	2000–3000 V
Working Temperature	-40°C to 200°C; continuous operation recommended at ≤180°C
Voltage	12V, 24V, 48V, 110V, 220V; customizable
Watt Density	0.1–1.0 W/cm²; typical 0.3–0.5 W/cm²
Thickness	1.5–2.0 mm
Temperature Sensors	K/J thermocouple, PT100, NTC sensor or thermal switch
Installation	3M adhesive bonding or screw mounting through holes
Lead Wire	Lead position and length customizable

Medical Silicone Heater Applications

Medical Equipment

Flexible silicone heating elements can be integrated into selected medical equipment where controlled and uniform surface heating is required. The thin construction is suitable for compact equipment with limited installation space.

Diagnostic and Analytical Equipment

Medical silicone heaters can provide localized temperature maintenance for selected components, containers and testing areas in diagnostic and analytical equipment.

Laboratory Instruments

The flexible heating element can be used for sample holders, laboratory instruments and other equipment requiring stable surface temperature during operation.

Fluid and Container Heating

Custom silicone heaters can be applied to selected containers, reservoirs and fluid-handling components to maintain the required operating temperature and help reduce condensation.

Custom Medical Silicone Rubber Heater

Medical and laboratory equipment often require heaters designed around specific equipment dimensions and operating conditions. EaseWise supports OEM customization according to drawings, samples or technical specifications.

• Custom length, width and heating area
• Rectangular, round or special shapes
• Cut-outs and openings
• Custom voltage and power
• Custom watt density
• 3M adhesive backing or mounting holes
• K-type or J-type thermocouple
• PT100, NTC sensor or thermal switch
• Custom lead-wire position and length

For a medical or laboratory heating project, please provide the heating size, voltage, power, operating temperature, installation method and temperature-control requirements. EaseWise can recommend a suitable heater configuration for your equipment.

Installation and Operating Considerations

• Maintain close thermal contact between the heater and heated surface.
• Avoid air gaps that may cause localized overheating.
• Use suitable temperature control and over-temperature protection.
• Confirm the heater voltage and power before installation.
• For continuous operation, select an appropriate watt density according to the heated material and operating temperature.
• For medical equipment, the heater configuration and temperature-control method should be matched to the equipment manufacturer’s requirements.

For medical equipment applications, heater selection and temperature control should be evaluated as part of the overall equipment design and applicable regulatory requirements. See the

FDA medical devices resources

for general information about medical device requirements.

Related Heating Products

Explore related heating and temperature-control solutions:

•
  Silicone Rubber Heater

  – the main product page for flexible silicone heating elements and custom surface heating solutions.
•
  Automotive Silicone Heater

  – flexible heating solutions for EV batteries, automotive components and cold-weather applications.
•
  PI Heater

  – ultra-thin flexible heating elements for compact equipment and space-limited applications.
•
  Thermocouple

  – temperature sensing solutions for heater monitoring and temperature control.

Medical Silicone Rubber Heater OEM Supplier

EaseWise supplies customized silicone heating elements for medical equipment, laboratory instruments, diagnostic devices and analytical applications. We support custom size, shape, voltage, power, watt density, sensor integration, adhesive backing, mounting holes and lead-wire configuration.
